Power Source

AC: 230 V AC, 50/60 Hz DC: 24 V DC

Power Consumption

AC: 537 W (at rated output), 240 W (EN60065), 21 W (no-signal)
   DC: 14.6 A (at rated output), 0.4 A (no-signal)

Rated Output

240 W

Input

2 program inputs (parallel), 0 dB*, 20 kΩ, balanced
   2 priority inputs (parallel), 0 dB*, 20 kΩ, balanced

Impedance

42 Ω (100 V)

S/N Ratio

80 dB or more

Total Harmonic Distortion

1 % or less (at rated output f = 1 kHz)

Frequency Response

80 Hz - 16 kHz, ±3 dB (at 1/3 rated output)

Ventilation

Fan cooling

Operating Temperature

0 ℃ to +40 ℃ (32 ゜F to 104 ゜F)

Operating Humidity

90 %RH or less (no condensation)

Finish

Panel: Aluminum, black, alumite

Dimensions

483.6 (W) × 132.6 (H) × 337.8 (D) mm (19.04" × 5.22" × 13.3")

Weight

13.4 kg (29.54 lb)

Accessory

Power cable (2 m (6.56 ft)) …1, Removable terminal plug (2 pins) …2,
   Removable terminal plug (3 pins) …2, Removable terminal plug (5 pins) …2,
   Fuse (4 A) …1

Option

Fault detector: YA-1000A
